Test Jack Low Profile Red

Product Code: K6067
Manufacturer: Keystone
UOM: EACH
This low profile double-entry design is recognized for its dependability, and allows dense packaging on .160" (4.06mm) centers. Side by side mounting. Closed entry design for use with .074 (1.88mm) to .084 (2.13mm) diameter tips. Mounts on .400" (10.16mm) centers in .052" (1.32mm) holes. Current rating: 5 Amps. Breakdown voltage 2100 VRMS. Contact resistance .010" (0.254mm).
Products specifications
DescriptionTest Jack
TypeLow Profile
ColourRed
MaterialNylon Body With Silver Plated Beryllium Copper Contact
Length11.68mm
Width3.96mm
Height5.59mm
Mounting Hole Diameter2.03mm
ProfileLow Profile, Horizontal
Tab Size1.22 x 3.3mm
Mounting TypeThru-Hole Mount (THM)
