    Picture of Test Jack Miniature Red

    Test Jack Miniature Red

    Product Code: K6049
    Manufacturer: Keystone
    UOM: EACH
    Half the size of standard jacks. Fit .080" (2.03mm) tips in either end. Mount on .200" (5.08mm), centers in .052" (1.32mm) holes. Can be spaced side by side on .160" (4.06mm) centers minimum. Current: 5 Amps. Breakdown voltage: 2100 VRMS. Capacitance 1.0 pF maximum.
    Download Datasheet
    Login to purchase this item
    Products specifications
    DescriptionTest Jack
    TypeMiniature
    ColourRed
    MaterialNylon Body With Silver Plated Beryllium Copper Contact
    Length5.28mm
    Width3.96mm
    Height5.16mm
    Mounting Hole Diameter2.03mm
    ProfileHorizontal
    Tab Size1.22 x 3.38mm
    Mounting TypeThru-Hole Mount (THM)
